The SRP Dynamic Line, available from 7.5 to 50 hp, is synonymous with versatility for applications requiring high performance in places where quiet operation is a must, and for spaces with difficult access or limited area. Designed to operate 24 hours continuous in places with ambient temperatures up to 113 °F, they are equipped with a three-phase IP 55 Totally Enclosed Electric motor and high efficiency filter which improves the compressed air quality. Dynamics microprocessor controller monitors the compressor operation, signals failures and provides local/remote operation.

REQUEST A QUOTE

  • SRP4020

  • SRP4025

  • SRP4030

  • SRP4050

  • Extreme Low Dba
  • Fully Computerized
  • 2 Year Warranty Air End
  • 1 Year Warranty Everything Else
  • 5 Year Warranty Available– Call For More Information
  • TEFC, IP55, degree of protection electric motors;
  • Automatic starters with phase and sequence failure detection;
  • Lubricated air-end;
  • Low maintenance costs;
  • Low oil consumption;
  • Coolers are on the top of the machine, improves heat recovery at customer’s facilities;
  • Modern design products;
  • High efficiency electric motors;
  • Thermostatic valve for working temperature control;
  • 24V Command panel.

 Operational Settings

  • Operation method – load/unload;
  • Remote/local;
  • Auto restart;
  • Maintenance time to air filter, oil filter and air/oil separator, oil and main motor grease;
  • Pressure and temperature units;
  • Starts per hour;
  • Error Messages;
  • Main motor and fan motor overloaded;
  • Phase fault or incorrect sequence;
  • Emergency;
  • High pressure;
  • High temperature;
  • Pressure and temperature sensor.

Advantages

  • Low noise level;
  • Low Speed;
  • Foam coated steel cabinet for noise reduction;
  • Low discharge temperature;
  • Oversized cooling system;
  • Longer oil and oil separator life time;
  • Compressor prepared to handle higher ambient temperatures;
  • Discharge temperature around 10°C above the ambient.

Low maintenance

  • Synthetic oil;
  • Robust belts;
  • Oversized separator elements – low ppm and longer life time;
  • Oversized separator elements – low ppm and longer life;
  • Easy access to components for quick and simple maintenance.

Safety

  • Belt guard;
  • 24 V command panel;
  • Fault and sequence phase relay;
  • High temperature protection.
